QS-525T Mini Track Loader
Looking for a reliable QS-525T Mini Track Loader?
The QS-525T tracked mini track loader combines 17.8 kW power and 1330 kg machine weight in a compact platform.
- Drive Configuration: tracked mini track loader.
- Rated Load: 882 lb.
- Bucket Capacity: 0.15 m3.
- Factory-Direct Support: OEM customization, compatible attachments and 1-year warranty.
Qisheng QS-525T is a tracked tracked mini track loader designed for material handling, cleanup, loading and unloading, drilling, snow pushing and light breaking work. The tracked chassis provides traction and stability on soft, uneven and compact jobsites.
QS-525T Mini Track Loader Specifications
| Specification | QS-525T (Tracked) |
|---|---|
| Engine | Laidong 385 / Yanmar 380 / Kubota D1105 |
| Number of Cylinders | 3 |
| Power | 17.8 kW |
| Operating Height | 2695 mm |
| Height of Bucket Hinge Pin | 2175 mm |
| Height to Top | 1520 mm |
| Overall Length With Bucket | 2694 mm |
| Overall Length Without Bucket | 2067 mm |
| Axis Distance | 1080 mm |
| Overall Width | 1070 mm |
| Minimum Ground Clearance | 94 mm |
| Departure Angle | 23 degrees |
| Rated Load | 882 lb |
| Vehicle Weight | 1330 kg |
| Working System Pressure | 250 bar |
| Working System Flow | 62.4 L/min |
| Travel System Pressure | 250 bar |
| Travel System Flow Display | 62.4 L/min |
| Working Pressure | 18 MPa |
| Gasoline Tank Capacity | 35 L |
| Travel Speed | 6 km/h |
Watch the QS-525T Mini Track Loader in Action
Why Choose Our QS-525T Mini Track Loader
1. Tracked Stability
The QS-525T uses a tracked chassis for traction and stability on soft or uneven ground.
2. 17.8 kW Power
The machine combines a 17.8 kW engine, 1330 kg vehicle weight, 882 lb rated load and 250 bar working pressure.
3. Attachment Flexibility
The machine supports material handling, cleanup, loading and unloading, drilling, snow pushing and breaking attachments.
Get Your Quotation
If you are interested in this tracked mini track loader, contact Qisheng Machinery for a factory-direct quotation, parameter sheet and shipping proposal.
You may also check our QS-525T Mini Track Loader, review the Loader equipment range, or contact our sales team for a configuration quotation.
FAQ
Q1: Is the QS-525T wheeled or tracked?
The QS-525T is the tracked version. The T suffix identifies the tracked configuration.
Q2: What is the rated load and vehicle weight?
The rated load is 882 lb and the vehicle weight is 1330 kg.
Q3: What engine options are listed?
The catalog lists Laidong 385, Yanmar 380 and Kubota D1105 engine options. Confirm availability before ordering.
Q4: What jobs is the QS-525T suitable for?
It supports material handling, cleanup, loading and unloading, drilling, snow pushing and breaking with compatible attachments.
Q5: What is the working pressure and flow?
The working system pressure is 250 bar and the working system flow is 62.4 L/min.
Q6: What is the travel speed?
The listed travel speed is 6 km/h.
Certifications & Compliance
Our machinery complies with international standards. We offer CE, ISO9001, EPA and Euro V certification support for compact loaders and construction machinery.
